BK5120 | BECKHOFF | CANopen Bus Coupler

₹ 18,872.94

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

BK5120

Original Equipment Manufacturer

BECKHOFF

Description
Number of Bus Terminals 64 (255 with K-bus extension)
Max. number of bytes fieldbus 16 Tx/Rx PDOs
Digital peripheral signals 960 inputs/outputs
Analog peripheral signals 60 inputs/outputs
Configuration via KS2000 or the controller
Number of PDOs (CANopen) 16 Tx/16 Rx
Additional CANopen features life, node guarding, emergency object, variable mapping, store/restore
Data transfer rates up to 1 Mbaud
Bus interface 1 x open style connector, 5-pin, included
Data transfer medium screened, twisted copper cable, 2 x signal, 1 x ground (recommended)
Power supply 24 V DC (-15%/+20%)
Input current 70 mA + (total K-bus current)/4, 500 mA max.
Starting current approx. 2.5 x continuous current
BECKHOFF

BK5120 | BECKHOFF | CANopen Bus Coupler

₹ 18,872.94
Number of Bus Terminals 64 (255 with K-bus extension)
Max. number of bytes fieldbus 16 Tx/Rx PDOs
Digital peripheral signals 960 inputs/outputs
Analog peripheral signals 60 inputs/outputs
Configuration via KS2000 or the controller
Number of PDOs (CANopen) 16 Tx/16 Rx
Additional CANopen features life, node guarding, emergency object, variable mapping, store/restore
Data transfer rates up to 1 Mbaud
Bus interface 1 x open style connector, 5-pin, included
Data transfer medium screened, twisted copper cable, 2 x signal, 1 x ground (recommended)
Power supply 24 V DC (-15%/+20%)
Input current 70 mA + (total K-bus current)/4, 500 mA max.
Starting current approx. 2.5 x continuous current
