SPARECRUX is NOT an authorized distributor for ELMEX

CBT 170 | ELMEX | Power Terminal Block, bolt-connection

₹ 600.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CBT 170

Original Equipment Manufacturer

ELMEX

Description

Product Type Power Terminal Block, bolt-connection
Rated Voltage 1000 V
Rated Current 192 A
Conductor Size (Stranded) 50-70 sq.mm
Rated Cross Section 70 sq.mm
Torque for Bolt 6 Nm
IEC Standard 60947-7-1
Short-Time Withstand Current 8.40 kA
Rated Impulse Withstand Voltage 8 kV
Pollution Degree 3
Housing Material Melamine
ELMEX

CBT 170 | ELMEX | Power Terminal Block, bolt-connection

₹ 600.00
Product Type Power Terminal Block, bolt-connection
Rated Voltage 1000 V
Rated Current 192 A
Conductor Size (Stranded) 50-70 sq.mm
Rated Cross Section 70 sq.mm
Torque for Bolt 6 Nm
IEC Standard 60947-7-1
Short-Time Withstand Current 8.40 kA
Rated Impulse Withstand Voltage 8 kV
Pollution Degree 3
Housing Material Melamine
