SPARECRUX is NOT an authorized distributor for ELMEX

CST10 | ELMEX | Feed-Through Terminal Block

₹ 255.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CST10

Original Equipment Manufacturer

ELMEX

Description
Type Feed-Through Terminal Block
Model CST10
Connection Method Screw Connection
Mounting Type TS 32 DIN Rail
Housing Material Melamine
Clamping Material CRCA (Cold Rolled Close Annealed)
Standard Color Khaki
Nominal Voltage 800 V
Nominal Current 57 A
Rated Cross-Section 10 mm²
Wire Size Range (Flexible) 0.5 mm² to 10 mm²
Wire Size Range (Solid) Up to 16 mm²
Torque 1.2 Nm
Short-Time Withstand Current 1.20 kA
Rated Impulse Withstand Voltage 8 kV
Width 10 mm
Length 40 mm
Height 49 mm
ELMEX

CST10 | ELMEX | Feed-Through Terminal Block

₹ 255.00
Type Feed-Through Terminal Block
Model CST10
Connection Method Screw Connection
Mounting Type TS 32 DIN Rail
Housing Material Melamine
Clamping Material CRCA (Cold Rolled Close Annealed)
Standard Color Khaki
Nominal Voltage 800 V
Nominal Current 57 A
Rated Cross-Section 10 mm²
Wire Size Range (Flexible) 0.5 mm² to 10 mm²
Wire Size Range (Solid) Up to 16 mm²
Torque 1.2 Nm
Short-Time Withstand Current 1.20 kA
Rated Impulse Withstand Voltage 8 kV
Width 10 mm
Length 40 mm
Height 49 mm
