CXDB35/10 | CONNECTWELL | Modular Distribution Blocks With 10 sq.mm Output Connection And 35 sq.mm Input Connection
₹ 163.84
● Available for backorder, with an estimated lead time of 8 to 12 weeks.
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
CXDB35/10 | CONNECTWELL | Modular Distribution Blocks With 10 sq.mm...
Manufacturer Part Number (MPN)
CXDB35/10
Original Equipment Manufacturer
CONNECTWELL
Description
Description
The CXDB range of distribution blocks is an ideal choice for a simplified distribution system. A screw clamp of the block provides a connection point for the incoming cable. All the terminals are internally connected and provide multiple connection points for the outgoing wires. A protective shield effectively shrouds the incoming connection.
| Rated Voltage | 1000 V |
| Rated Current - Input Side | 125 A |
| Rated Current - Output Side | 41 A |
| Tightening Torque - Input Side | 2.5 Nm |
| Housing Material | Polyamide |
| Product Function | Compact Distribution Block |
| Wire Entry Orientation | Top |
| Mounting Possibility | DIN 35/DIN 35-15 Rail |
| Operated by | Screw Driver |
| Rated Surge Voltage | 8 KV |
| Pollution Degree | 3 |
