SPARECRUX is an authorized distributor for HENSEL ELECTRIC

KM 9065 | HENSEL | Cable junction box

₹ 840.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KM 9065

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

KM 9065

  • 2.5-6 mm², Cu 3~
  • with terminals
  • 5-pole per pole 4 x 2.5 mm² sol, 4 x 4 mm² sol, 3 x 6 mm² sol, 2 x 10 mm² sol
  • cable entry via knockouts, cable entry to be ordered separately
  • for normal environment and protected outdoor
  • colour: grey, RAL 7035

Technical Data

rated insulation voltage Ui = 690 V a.c./d.c.
tightening torque for terminal 1.5 Nm
material thermoplastic
degree of protection IP 65
width 139 mm
height 119 mm
depth 70 mm
weight 0,246 kg
in accordance with IEC 60670-22
Km 9065 | Hensel Cable Junction Box
HENSEL ELECTRIC

KM 9065 | HENSEL | Cable junction box

₹ 840.00

KM 9065

Technical Data

rated insulation voltage Ui = 690 V a.c./d.c.
tightening torque for terminal 1.5 Nm
material thermoplastic
degree of protection IP 65
width 139 mm
height 119 mm
depth 70 mm
weight 0,246 kg
in accordance with IEC 60670-22
