DPBB120 | ELMEX | High-Current Terminal Block

₹ 3,200.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

DPBB120

Original Equipment Manufacturer

ELMEX

Description
Type High-Current Terminal Block
Connection Method Bolt Connection
Mounting Type TS 35/7.5, TS 35/15, TS 32 DIN Rail
Housing Material Polyamide 6.6
Clamping Material Brass
Standard Color Gray
Nominal Voltage 1000 V
Nominal Current 269 A
Rated Cross-Section 120 mm²
Wire Size Range 25 mm² to 120 mm² (both stranded and solid wires)
Torque 6 Nm
Short-Time Withstand Current 14.4 kA
Rated Impulse Withstand Voltage 12 kV
Width 100 mm
Height 44 mm
Thickness 37 mm
