DPBB70 | ELMEX | High-Current Bolt Terminal Block

₹ 1,002.50

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

DPBB70

Original Equipment Manufacturer

ELMEX

Description

Type High-Current Bolt Terminal Block
Connection Method Bolt Connection
Mounting Type DIN Rail TS35/7.5, TS35/15, TS32
Material Polyamide 6.6 Housing, Stainless Steel Clamping
Standard Color Gray
Nominal Voltage (IEC) 1000 V
Nominal Current (IEC) 192 A
Rated Cross Section (IEC) 70 mm²
Torque 3 Nm
Short-Time Withstand Current 8.4 kA
Rated Impulse Withstand Voltage 12 kV
Flexible Wire 10 mm² to 70 mm²
Solid Wire 10 mm² to 70 mm²
Width 90 mm
Height 44 mm
Thickness 37 mm
