SPARECRUX is NOT an authorized distributor for ELMEX

DST4 | ELMEX | Screwless (Spring Clamp) Feed-Through Terminal Block

₹ 4,900.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

DST4

Original Equipment Manufacturer

ELMEX

Description
Type Screwless (Spring Clamp) Feed-Through Terminal Block
Voltage Rating 800 V
Current Rating 32 A
Wire Size Stranded Wire: 0.5 mm² to 4 mm²
Solid Wire: Up to 4 mm²
Torque 0.5 Nm
Mounting Type DIN Rail TS 35/7.5, TS 35/15
Material Housing: Polyamide 6.6
Clamping Material: CRCA (Cold Rolled Close Annealed)
Standard Color Gray
Height 49 mm
Width 40 mm
Thickness 8 mm
ELMEX

DST4 | ELMEX | Screwless (Spring Clamp) Feed-Through Terminal Block

₹ 4,900.00
Type Screwless (Spring Clamp) Feed-Through Terminal Block
Voltage Rating 800 V
Current Rating 32 A
Wire Size Stranded Wire: 0.5 mm² to 4 mm²
Solid Wire: Up to 4 mm²
Torque 0.5 Nm
Mounting Type DIN Rail TS 35/7.5, TS 35/15
Material Housing: Polyamide 6.6
Clamping Material: CRCA (Cold Rolled Close Annealed)
Standard Color Gray
Height 49 mm
Width 40 mm
Thickness 8 mm
