DVP08SM11N | DELTA ELECTRONICS| Input Module DIN Rail 100 ~ 240VAC, 24VDC

₹ 0.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

DVP08SM11N

Original Equipment Manufacturer

DELTA ELECTRONICS

Description
Specification Details
Power Supply 24VDC (−15% to +20%)
Number of Inputs and Type Digital - 8
Number of Outputs and Type None
Fuse Capacity ES: 2A / 250VAC; SV: 2.5A / 30VDC
Power Consumption 1W
Program Capacity 30,000 Steps
Spike Voltage Durability 1500VAC (Primary-secondary), 1500VAC (Primary-PE), 500VAC (Secondary-PE)
Insulation Impedance > 5 MΩ (all I/O point-to-ground at 500VDC)
Noise Immunity ESD: 8kV Air Discharge
EFT: Power Line 2kV
Digital I/O 1kV
Analog & Communication I/O 1kV
RS: 26 MHz–1GHz, 10V/m
Earth Grounding wire diameter must be ≥ power supply cable diameter; ensure proper grounding when multiple PLCs are used
Storage Temperature Range −25°C to 70°C
Operating Temperature Range 0°C to 55°C
Storage Humidity Matches storage temperature range
Operating Humidity Matches operating temperature range
Response Time 10 ms
DELTA ELECTRONICS

DVP08SM11N | DELTA ELECTRONICS| Input Module DIN Rail 100 ~ 240VAC, 24VDC

₹ 0.00
Specification Details
Power Supply 24VDC (−15% to +20%)
Number of Inputs and Type Digital - 8
Number of Outputs and Type None
Fuse Capacity ES: 2A / 250VAC; SV: 2.5A / 30VDC
Power Consumption 1W
Program Capacity 30,000 Steps
Spike Voltage Durability 1500VAC (Primary-secondary), 1500VAC (Primary-PE), 500VAC (Secondary-PE)
Insulation Impedance > 5 MΩ (all I/O point-to-ground at 500VDC)
Noise Immunity ESD: 8kV Air Discharge
EFT: Power Line 2kV
Digital I/O 1kV
Analog & Communication I/O 1kV
RS: 26 MHz–1GHz, 10V/m
Earth Grounding wire diameter must be ≥ power supply cable diameter; ensure proper grounding when multiple PLCs are used
Storage Temperature Range −25°C to 70°C
Operating Temperature Range 0°C to 55°C
Storage Humidity Matches storage temperature range
Operating Humidity Matches operating temperature range
Response Time 10 ms
