E2F-X5E1 2M | OMRON | Cylindrical Proximity Sensor

₹ 11,498.80

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

E2F-X5E1 2M

Original Equipment Manufacturer

OMRON

Description
Parameter Specification
Sensing Head Size M18
Type Cylinder type (with screw), Shielded
Power Source DC Three-wire model
Sensing Distance 5 mm ±10%
Setting Distance 0 to 4 mm
Differential Distance 10% max. of sensing distance
Sensing Object Ferrous metal (lower sensitivity with non-ferrous metals)
Standard Sensing Object Iron 18 x 18 x 1 mm
Response Frequency 600 Hz (Average value)
Power Supply Voltage 12 to 24 VDC (ripple 10% max. p-p)
Operating Voltage Range 10 to 30 VDC
Current Consumption 17 mA max.
Control Output (Type) NPN
Control Output (Switching Capacity) 200 mA max.
Control Output (Residual Voltage) 2 V max. (at 200 mA, 2 m cable)
Indicator Detection indicator (red)
Operation Mode NO
Protective Circuit Output short-circuit protection, reverse polarity protection, surge suppressor
Ambient Temperature (Operating) -25°C to 70°C
