SPARECRUX is NOT an authorized distributor for BECKHOFF

EL2004 | BECKHOFF | EtherCAT Terminal, 4-channel Digital Output, 24 V DC, 0.5 A

₹ 8,024.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

EL2004

Original Equipment Manufacturer

BECKHOFF

Description

Connection technology 2-wire
Number of outputs 4
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic, inductive, lamp load
Distributed clocks
Max. output current 0.5 A (short-circuit proof) per channel
Short-circuit current typ. < 2 A
Reverse voltage protection yes
Breaking energy < 150 mJ/channel
Switching times typ. TON: 60 µs, typ. TOFF: 300 µs
Current consumption E-bus typ. 100 mA
Current consumption power contacts typ. 15 mA + load
Bit width in the process image 4 outputs
Configuration no address or configuration setting
Electrical isolation 500 V (E-bus/field potential)
Weight approx. 55 g
