EL3064 | BECKHOFF | EtherCAT Terminal, 4-channel Analog Input, Voltage, 0…10 V, 12 Bit, Single-ended

₹ 16,255.68

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

EL3064

Original Equipment Manufacturer

BECKHOFF

Description
Number of inputs 4 (single-ended)
Power supply via the E-bus
Signal voltage 0…10 V
Distributed clocks –
Internal resistance > 130 kΩ
Input filter limit frequency 1 kHz
Dielectric strength max. 30 V
Conversion time 0.625 ms default setting, configurable, multiplex
Resolution 12 bit (16 bit presentation incl. sign)
Measurement error/uncertainty < ±0.3% (relative to full scale value)
Electrical isolation 500 V (E-bus/signal voltage)
Current consumption E-bus typ. 130 mA
Current consumption power contacts –
Bit width in the process image inputs: 16 byte
Special features activatable FIR/IIR filters, limit value monitoring
Weight approx. 60 g
Operating temperature -25…+60°C
Storage temperature -40…+85°C
Relative humidity 95%, no condensation
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Pluggable wiring for all ESxxxx terminals
Protect. rating/installation pos. IP20/variable
Approvals/markings CE, CCC, UL, ATEX, IECEx
Ex marking ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
