SPARECRUX is NOT an authorized distributor for BECKHOFF

EL1018 | BECKHOFF | EtherCAT Terminal, 8-channel Digital Input, 24 V DC, 10 µs

₹ 3,901.36

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

EL1018

Original Equipment Manufacturer

BECKHOFF

Description

Connection technology 1-wire
Specification EN 61131-2, type 1/3
Number of inputs 8
Nominal voltage 24 V DC (-15%/+20%)
“0” signal voltage -3…+5 V (EN 61131-2, type 3)
“1” signal voltage 11…30 V (EN 61131-2, type 3)
Input current typ. 3 mA (EN 61131-2, type 3)
Input filter typ. 10 µs
Distributed clocks
Current consumption power contacts typ. 2 mA + load
Current consumption E-bus typ. 90 mA
Electrical isolation 500 V (E-bus/field potential)
Configuration no address or configuration setting
Special features standard input terminal for fast signals (filter 10 μs)
Weight approx. 55 g
Operating temperature -25…+60°C
Storage temperature -40…+85°C
BECKHOFF

EL1018 | BECKHOFF | EtherCAT Terminal, 8-channel Digital Input, 24 V DC, 10 µs

₹ 3,901.36
Connection technology 1-wire
Specification EN 61131-2, type 1/3
Number of inputs 8
Nominal voltage 24 V DC (-15%/+20%)
“0” signal voltage -3…+5 V (EN 61131-2, type 3)
“1” signal voltage 11…30 V (EN 61131-2, type 3)
Input current typ. 3 mA (EN 61131-2, type 3)
Input filter typ. 10 µs
Distributed clocks
Current consumption power contacts typ. 2 mA + load
Current consumption E-bus typ. 90 mA
Electrical isolation 500 V (E-bus/field potential)
Configuration no address or configuration setting
Special features standard input terminal for fast signals (filter 10 μs)
Weight approx. 55 g
Operating temperature -25…+60°C
Storage temperature -40…+85°C
