SPARECRUX is NOT an authorized distributor for BECKHOFF

EL9400 | BECKHOFF | Power Supply Terminal For E-bus

₹ 9,753.41

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

EL9400

Original Equipment Manufacturer

BECKHOFF

Description

Technology power supply terminal
Input voltage 24 V DC (-15%/+20%)
Input current typ. 70 mA + (E-bus/4)
Output voltage 5 V for E-bus supply
Output current 2 A
Electrical isolation 500 V (E-bus/field potential)
Insulation voltage input/output
Power contacts max. 24 V DC/max. 10 A
Weight approx. 65 g
Operating temperature 0…55°C
Storage temperature -25…+85°C
Relative humidity 95%, no condensation
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
Pluggable wiring for all ESxxxx terminals
Protect. rating/installation pos. IP20/variable
BECKHOFF

EL9400 | BECKHOFF | Power Supply Terminal For E-bus

₹ 9,753.41
Technology power supply terminal
Input voltage 24 V DC (-15%/+20%)
Input current typ. 70 mA + (E-bus/4)
Output voltage 5 V for E-bus supply
Output current 2 A
Electrical isolation 500 V (E-bus/field potential)
Insulation voltage input/output
Power contacts max. 24 V DC/max. 10 A
Weight approx. 65 g
Operating temperature 0…55°C
Storage temperature -25…+85°C
Relative humidity 95%, no condensation
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
Pluggable wiring for all ESxxxx terminals
Protect. rating/installation pos. IP20/variable
