FBS-24MCT2-D24 | FATEK AUTOMATION | Advanced Main Unit, 14 Input And 10 Output

₹ 26,796.07

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

FBS-24MCT2-D24

Original Equipment Manufacturer

FATEK AUTOMATION

Description

Feature Specification
Model FBs-24MCT2-D24
Inputs 14 digital 24V DC inputs (4 high-speed 200 kHz, 4 medium-speed 20 kHz, 6 medium-speed 5 kHz)
Outputs 10 NPN transistor outputs (sink type)
Communication Ports 1 RS232 or USB port (expandable up to 5 ports)
I/O Expansion Expandable up to 256 I/O points
Power Supply 24V DC
Real-Time Clock (RTC) Built-in RTC
Execution Speed 0.33 µs per sequential instruction
Program Capacity 20K words
Communication Interface Port 0: RS232; Ports 1–4: RS232, RS485, Ethernet, or CANopen
Programming Software WinProLadder (free)
