GVAD0110 | SCHNEIDER ELECTRIC | TeSys GV2 & GV3 - auxiliary contact - 1 NO + 1 NC (fault)

₹ 6,814.95

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

GVAD0110

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Product Type Auxiliary Contact Block (fault signalling)
Auxiliary Contacts 1 NO + 1 NC (fault signal)
Rated Operational Voltage 48–690 V AC; 24–240 V DC
Insulation Voltage (Ui) 690 V (IEC), 300 V (UL/CSA)
Thermal Current (Ith) 6 A (normal), 2.5 A fault signalling
Minimum Switching 5 mA / 17 V
Rated Operational Power (AC‑15) 300 VA @48 V … 850 VA @380‑415 V
Rated Operational Power (DC‑13) 240 W @48 V, 140 W @24 V, 180 W @60 V
Mechanical Durability 100 000 cycles
Mounting Left‑side of GV2/GV3 circuit breakers, screw clamp terminals
Dimensions (H × W × D) 89 mm × 9.3 mm × 66 mm
Weight 0.055 kg
