SPARECRUX is an authorized distributor for HENSEL

KF0600G | HENSEL | Cable Junction Box

₹ 7,281.75

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KF0600G

Original Equipment Manufacturer

HENSEL

Description

Specification Details
Rated insulation voltage (Ui) 1000 V
Type of lid fastening Quick locking: opening and closing by quarter turn, locked position well visible (open - locked)
Delivered accessories External brackets, retaining strap, sealing plug
IP degree of protection IP66, IP67, IP69
IP67 specification Temporary submersion up to 1 m / 30 min
IP69 specification Water pressure max. 100 bar, water temperature max. 80 °C, distance ≥ 0.15 m
Impact strength IK09
Sealable without accessories Yes
Application area Outdoor installation
Maximum ambient temperature (24h) 55 °C
Ambient temperature range -25 °C up to +70 °C
Relative humidity ≤ 50 % at 40 °C, ≤ 100 % at 25 °C
Material Polycarbonate
Glow wire test (IEC 60695-2-11) 960 °C
UL 94 V-0
Temperature resistance -25 °C up to +100 °C
Halogen-free Yes
Silicone-free Yes
Weatherproof Yes (resistant to UV exposure due to solar radiation, ice and sea water, corrosion, temperature resistant, impact-resistant)
