SPARECRUX is NOT an authorized distributor for BECKHOFF

KL-2134 | BECKHOFF | Bus Terminal, 4-channel Digital Output, 24 V DC, 0.5 A, Reverse Voltage Protection

₹ 2,794.78

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL-2134

Original Equipment Manufacturer

BECKHOFF

Description

Connection technology 2-/3-wire
Number of outputs 4
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic, inductive, lamp load
Max. output current 0.5 A (short-circuit proof) per channel
Short-circuit current < 2 A
Breaking energy < 150 mJ/channel
Reverse voltage protection yes
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts typ. 30 mA + load
Current consumption K-bus typ. 9 mA
Bit width in the process image 4 outputs
Configuration no address or configuration setting
Weight approx. 70 g
BECKHOFF

KL-2134 | BECKHOFF | Bus Terminal, 4-channel Digital Output, 24 V DC, 0.5 A, Reverse Voltage Protection

₹ 2,794.78
Connection technology 2-/3-wire
Number of outputs 4
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic, inductive, lamp load
Max. output current 0.5 A (short-circuit proof) per channel
Short-circuit current < 2 A
Breaking energy < 150 mJ/channel
Reverse voltage protection yes
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts typ. 30 mA + load
Current consumption K-bus typ. 9 mA
Bit width in the process image 4 outputs
Configuration no address or configuration setting
Weight approx. 70 g
