SPARECRUX is NOT an authorized distributor for BECKHOFF

KL-2602 | BECKHOFF | Bus Terminal, 2-channel Relay Output, 230 V AC, 30 V DC, 5 A

₹ 3,114.61

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL-2602

Original Equipment Manufacturer

BECKHOFF

Description
Number of outputs 2 x make contacts for power contact
Nominal voltage 230 V AC/30 V DC
Load type ohmic, inductive, lamp load
Max. output current 5 A per channel
Switching current 5 A AC/DC (ohmic)/2 A AC/DC (inductive)
Ohmic switching current 5 A AC/DC
Inductive switching current 2 A AC/DC
Minimum permitted load 10 mA at 5 V DC
Lamp test, electronic ballast max. 5 A starting current (4 x 58 W)
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts load only
Current consumption K-bus typ. 80 mA
BECKHOFF

KL-2602 | BECKHOFF | Bus Terminal, 2-channel Relay Output, 230 V AC, 30 V DC, 5 A

₹ 3,114.61
Number of outputs 2 x make contacts for power contact
Nominal voltage 230 V AC/30 V DC
Load type ohmic, inductive, lamp load
Max. output current 5 A per channel
Switching current 5 A AC/DC (ohmic)/2 A AC/DC (inductive)
Ohmic switching current 5 A AC/DC
Inductive switching current 2 A AC/DC
Minimum permitted load 10 mA at 5 V DC
Lamp test, electronic ballast max. 5 A starting current (4 x 58 W)
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts load only
Current consumption K-bus typ. 80 mA
