SPARECRUX is NOT an authorized distributor for BECKHOFF

KL1501 | BECKHOFF | Bus Terminal, 1-channel Digital Input, Counter, 24 V DC, 100 kHz

₹ 4,891.29

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL1501

Original Equipment Manufacturer

BECKHOFF

Description

Connection technology 1 x up/down counter, 2 x up or down counter
Specification EN 61131-2, type 1, “0”: < 5 V DC, “1”: > 15 V DC, typ. 5 mA
Number of counters 1 or 2
Nominal voltage 24 V DC (-15%/+20%)
“0” signal voltage -3…+5 V (EN 61131-2, type 1)
“1” signal voltage 15…30 V (EN 61131-2, type 1)
Counting frequency max. 100 kHz (2 kHz for switching up/down)
Counter depth 32 bit
Input current typ. 5 mA (EN 61131-2, type 1)
Max. output current 24 V/0.5 A (short-circuit proof) per channel
Current consumption K-bus typ. 50 mA
Current consumption power contacts load only
BECKHOFF

KL1501 | BECKHOFF | Bus Terminal, 1-channel Digital Input, Counter, 24 V DC, 100 kHz

₹ 4,891.29
Connection technology 1 x up/down counter, 2 x up or down counter
Specification EN 61131-2, type 1, “0”: < 5 V DC, “1”: > 15 V DC, typ. 5 mA
Number of counters 1 or 2
Nominal voltage 24 V DC (-15%/+20%)
“0” signal voltage -3…+5 V (EN 61131-2, type 1)
“1” signal voltage 15…30 V (EN 61131-2, type 1)
Counting frequency max. 100 kHz (2 kHz for switching up/down)
Counter depth 32 bit
Input current typ. 5 mA (EN 61131-2, type 1)
Max. output current 24 V/0.5 A (short-circuit proof) per channel
Current consumption K-bus typ. 50 mA
Current consumption power contacts load only
