KL2008 | BECKHOFF | Bus Terminal, 8-channel digital output, 24 V DC, 0.5 A

₹ 5,976.45

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL2008

Original Equipment Manufacturer

BECKHOFF

Description
Specification Details
Technical Data KL2808
Connection Technology 2-wire
Number of Outputs 8
Nominal Voltage 24 V DC (-15%/+20%)
Load Type Ohmic, inductive, lamp load
Max Output Current 0.5 A (short-circuit proof) per channel
Short-Circuit Current < 2 A
Breaking Energy < 150 mJ/channel
Reverse Voltage Protection Yes
Electrical Isolation 500 V (K-bus/field potential)
Current Consumption Power Contacts Typical 15 mA + load
Current Consumption K-Bus Typical 20 mA
Bit Width in Process Image 8 outputs
Configuration No address or configuration setting
Weight Approx. 65 g
Operating Temperature 0…55°C
Storage Temperature -25…+85°C
Relative Humidity 95%, no condensation
Vibration/Shock Resistance Conforms to EN 60068-2-6 / EN 60068-2-27
EMC Immunity/Emission Conforms to EN 61000-6-2 / EN 61000-6-4
Protection Rating / Installation Position IP20 / variable (see documentation)
Approvals / Markings CE, CCC, UL, ATEX, IECEx, DNV GL
