SPARECRUX is NOT an authorized distributor for BECKHOFF

KL2012 | BECKHOFF | Bus Terminal, 2-channel Digital Output, 24 V DC, 0.5 A

₹ 38,080.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL2012

Original Equipment Manufacturer

BECKHOFF

Description
Number of outputs 2
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic, inductive, lamp load
Max. output current 0.5 A (short-circuit proof) per channel
Short-circuit current < 2 A
Breaking energy < 150 mJ/channel
Reverse voltage protection –
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts typ. 15 mA + load
Current consumption K-bus typ. 5 mA
Bit width in the process image 2 outputs
Configuration no address or configuration setting
Weight approx. 55 g
BECKHOFF

KL2012 | BECKHOFF | Bus Terminal, 2-channel Digital Output, 24 V DC, 0.5 A

₹ 38,080.00
Number of outputs 2
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic, inductive, lamp load
Max. output current 0.5 A (short-circuit proof) per channel
Short-circuit current < 2 A
Breaking energy < 150 mJ/channel
Reverse voltage protection –
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts typ. 15 mA + load
Current consumption K-bus typ. 5 mA
Bit width in the process image 2 outputs
Configuration no address or configuration setting
Weight approx. 55 g
