SPARECRUX is NOT an authorized distributor for BECKHOFF

KL-3172 | BECKHOFF | Bus Terminal, 2-channel Analog Input, Voltage, 0…2 V, 16 bit, Differential, High-precision

₹ 23,200.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL-3172

Original Equipment Manufacturer

BECKHOFF

Description
Number of inputs 2
Power supply via the K-bus
Signal voltage 0…2 V
Technology differential input
Internal resistance > 70 kΩ
Common-mode voltage UCM max. 10 V
Conversion time 140 ms, configurable
Filter 50 Hz, configurable
Resolution 16 bit
Measurement error/uncertainty < ±0.05% (relative to full scale value)
Electrical isolation 500 V (K-bus/signal voltage)
Current consumption power contacts –
Current consumption K-bus typ. 85 mA
Bit width in the process image input: 2 x 16 bit data (2 x 8 bit control/status optional)
Special features increased measuring accuracy
Weight approx. 70 g
BECKHOFF

KL-3172 | BECKHOFF | Bus Terminal, 2-channel Analog Input, Voltage, 0…2 V, 16 bit, Differential, High-precision

₹ 23,200.00
Number of inputs 2
Power supply via the K-bus
Signal voltage 0…2 V
Technology differential input
Internal resistance > 70 kΩ
Common-mode voltage UCM max. 10 V
Conversion time 140 ms, configurable
Filter 50 Hz, configurable
Resolution 16 bit
Measurement error/uncertainty < ±0.05% (relative to full scale value)
Electrical isolation 500 V (K-bus/signal voltage)
Current consumption power contacts –
Current consumption K-bus typ. 85 mA
Bit width in the process image input: 2 x 16 bit data (2 x 8 bit control/status optional)
Special features increased measuring accuracy
Weight approx. 70 g
