KL3312 | BECKHOFF | Bus Terminal, 2-channel Analog Input, Temperature, Thermocouple, 16 Bit

₹ 20,584.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL3312

Original Equipment Manufacturer

BECKHOFF

Description
Number of inputs 2
Power supply via the K-bus
Technology 2-wire
Thermocouple sensor types types J, K, L, B, E, N, R, S, T, U (default setting type K), mV measurement
Measuring range in the range defined in each case for the sensor (default setting: type K; -100…+1370°C);
mV measurement: ±30 mV…±120 mV
Connection method 2-wire
Conversion time ~ 250 ms
Wiring fail indication yes
Resolution 0.1°C per digit
Measurement error/uncertainty < ±0.5% (relative to full scale value)
Electrical isolation 500 V (K-bus/signal voltage)
Current consumption power contacts – (no power contacts)
Current consumption K-bus typ. 65 mA
BECKHOFF

KL3312 | BECKHOFF | Bus Terminal, 2-channel Analog Input, Temperature, Thermocouple, 16 Bit

₹ 20,584.00
Number of inputs 2
Power supply via the K-bus
Technology 2-wire
Thermocouple sensor types types J, K, L, B, E, N, R, S, T, U (default setting type K), mV measurement
Measuring range in the range defined in each case for the sensor (default setting: type K; -100…+1370°C);
mV measurement: ±30 mV…±120 mV
Connection method 2-wire
Conversion time ~ 250 ms
Wiring fail indication yes
Resolution 0.1°C per digit
Measurement error/uncertainty < ±0.5% (relative to full scale value)
Electrical isolation 500 V (K-bus/signal voltage)
Current consumption power contacts – (no power contacts)
Current consumption K-bus typ. 65 mA
