KL-5101 | BECKHOFF | Bus Terminal, 1-channel Encoder Interface, Incremental, 5 V DC (DIFF RS422, TTL), 1 MHz

₹ 20,955.58

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL-5101

Original Equipment Manufacturer

BECKHOFF

Description
Technology incremental encoder interface RS422
Number of channels 1 incremental encoder + 1 input
Encoder connection A, A (inv), B, B (inv), C,C (inv), differential inputs (RS422); status input 5 V DC; gate/latch input 24 V DC
Encoder operating voltage 5 V DC
Encoder output current 0.5 A
Counter 16 bit, binary
Limit frequency 4 million increments/s (with 4-fold evaluation)
Quadrature decoder 1-, 2-, 4-fold evaluation
Zero-pulse latch 16 bit
Commands read, set, enable
Power supply 24 V DC (-15%/+20%)
Current consumption power contacts – (no power contacts)
Current consumption K-bus typ. 60 mA
Bit width in the process image input: 1 x 16 bit data, 1 x 8 bit control/status
Weight approx. 85 g
