KL6201 | BECKHOFF | Bus Terminal, 1-channel Communication Interface, ASi, Master, Without Power Contacts

₹ 65,600.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL6201

Original Equipment Manufacturer

BECKHOFF

Description
Technology AS-Interface master terminal (M3)
Number of channels 1
Number of slaves 31 for V 2.0, 62 for V 2.1
Specification version AS-Interface V 2.0, V 2.1
Slave types digital and analog
Diagnostics power failure, slave failure, parameterization fault
AS-Interface address
assignment		 via configuration or automatic
Cycle time max. 5 ms (31 devices)
Connection 2 lines via spring force technology
Current consumption K-bus typ. 55 mA (K-bus), typ. 60 mA (AS-Interface)
Current consumption power contacts – (no power contacts)
Electrical isolation 500 V (AS-Interface/K-bus)
Power contacts no
Bit width in the process image selectable: 12 bytes, 22 bytes or 38 bytes, of which 6 bytes parameter interface
Configuration via fieldbus parameter interface, DP-V1 or Bus Coupler through KS2000
Weight approx. 55 g
Operating temperature 0…55°C
Storage temperature -25…+85°C
BECKHOFF

KL6201 | BECKHOFF | Bus Terminal, 1-channel Communication Interface, ASi, Master, Without Power Contacts

₹ 65,600.00
Technology AS-Interface master terminal (M3)
Number of channels 1
Number of slaves 31 for V 2.0, 62 for V 2.1
Specification version AS-Interface V 2.0, V 2.1
Slave types digital and analog
Diagnostics power failure, slave failure, parameterization fault
AS-Interface address
assignment		 via configuration or automatic
Cycle time max. 5 ms (31 devices)
Connection 2 lines via spring force technology
Current consumption K-bus typ. 55 mA (K-bus), typ. 60 mA (AS-Interface)
Current consumption power contacts – (no power contacts)
Electrical isolation 500 V (AS-Interface/K-bus)
Power contacts no
Bit width in the process image selectable: 12 bytes, 22 bytes or 38 bytes, of which 6 bytes parameter interface
Configuration via fieldbus parameter interface, DP-V1 or Bus Coupler through KS2000
Weight approx. 55 g
Operating temperature 0…55°C
Storage temperature -25…+85°C
