SPARECRUX is NOT an authorized distributor for INA

KWVE15BS | INA | Recirculating ball bearing carriage

₹ 12,409.76

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KWVE15BS

Original Equipment Manufacturer

INA

Description



Type Recirculating ball bearing carriage
Design Four-row, narrow carriage
Height (H) 24 mm
Width (B) 34 mm
Overall Length (L) 61.2 mm
Dynamic Load Rating (C) 7,200 N
Static Load Rating (C₀) 14,500 N
Static Moment Rating M₀ₓ 150 Nm
Static Moment Rating M₀ᵧ 100 Nm
Static Moment Rating M₀𝓏 100 Nm
Seal Type No seal
Preload Light
Accuracy Class G3
Material Steel and plastic
Lubrication Relubrication via lubrication nipple
Temperature Range -10°C to +80°C
Weight Approximately 0.16 kg
