LC1K0610F7 | SCHNEIDER ELECTRIC | TeSys K contactor - 3P - AC-3 <= 440 V 6 A - 1 NO aux. - 110 V AC coil

₹ 1,069.51

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LC1K0610F7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (TeSys K)
Device Type Contactor, 3‑pole, 3 NO
Rated Current 6 A (AC‑3 up to ≤440 V)
Coil Voltage 110 V AC, 50/60 Hz
Motor Power Ratings 1.5 kW @ 220–230 V, 2.2 kW @ 380–415 V, up to 3 kW @ 440–690 V (AC‑3) :contentReference[oaicite:1]{index=1}
Impulse Withstand Voltage (Uimp) 8 kV, Overvoltage Category III :contentReference[oaicite:2]{index=2}
Thermal Current (Ith) 20 A (power), 10 A (signalling) at ≤50 °C :contentReference[oaicite:3]{index=3}
Making Capacity (Irms) 110 A AC (IEC 60947 / NF C 63‑110) :contentReference[oaicite:4]{index=4}
Breaking Capacity 110 A @415 V, 110 A @440 V, 80 A @500 V, 70 A @660‑690 V (IEC 60947) :contentReference[oaicite:5]{index=5}
Short-time Withstand (Icw) 20 A for ≥15 min; 90 A for 1 s; 85 A for 5 s; 80 A for 10 s; 60 A for 30 s; 45 A for 1 min; 40 A for 3 min :contentReference[oaicite:6]{index=6}
Auxiliary Contact 1 NO (integrated) :contentReference[oaicite:7]{index=7}
Mounting DIN-rail or Panel (screw‑clamp terminals) :contentReference[oaicite:8]{index=8}
Terminals Screw clamp: solid/flexible cables 0.34–4 mm²; tightening torque 1.3 N·m :contentReference[oaicite:9]{index=9}
Dimensions (H×W×D) 58 × 45 × 57 mm :contentReference[oaicite:10]{index=10}
Weight ≈ 0.18 kg (≈178 g) :contentReference[oaicite:11]{index=11}
Standards / Certifications IEC 60947‑4‑1, IEC 60947‑5‑1, UL 508, CSA C22.2, NF C 63‑110, VDE 0660; RoHS / Green Premium compliant :contentReference[oaicite:12]{index=12}
Operating Temp. −25 °C to +50 °C; Storage: −50 °C to +80 °C :contentReference[oaicite:13]{index=13}
Mechanical Endurance 10 million cycles; Electrical endurance ~1.3 M cycles at 6 A AC‑3 @ ≤440 V :contentReference[oaicite:14]{index=14}
