LC2K0901E7 | SCHNEIDER ELECTRIC | TeSys K Reversing Contactor - 3P - AC-3 <= 440 V 9 A - 1 NC - 48 V AC Coil

₹ 5,001.75

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LC2K0901E7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Series / Range TeSys K
Function Reversing Contactor (with pre-wired reversing power busbar and mechanical interlock)
Poles / Contacts 3P – 3 NO main contacts; Aux: 1 NC
Rated Operational Current (Ie) 9 A at AC‑3 ≤ 440 V; 20 A at AC‑1 ≤ 440 V (up to 16 A @ 690 V AC‑1)
Motor Power Rating 4 kW @ 380–690 V AC; 2.2 kW @ 220–230 V AC
Control Coil Voltage 48 V AC, 50/60 Hz
Utilisation Categories AC‑1 / AC‑3 / AC‑4
Rated Insulation Voltage (Ui) 600 V (UL), 690 V (IEC)
Impulse Withstand Voltage (Uimp) 8 kV
Conventional Free-Air Thermal Current (Ith) 20 A at 50 °C (power circuit); 10 A at 50 °C (signalling circuit)
Rated Breaking Capacity 110 A AC (at 415–440 V, IEC/NF C)
Short-Time Withstand Current (Icw) 90 A (1 s); 45 A (1 min) @ 50 °C, power circuit
Electrical Durability ≈ 1.3 million cycles (9 A, AC‑3); 0.18 million cycles (20 A, AC‑1)
Mechanical Durability ≈ 5 million cycles
Operating Rate Up to 3600 cycles/hour
Make Capacity (Irms) 110 A AC for power & signalling circuits
Operating Time 10–20 ms (on/off)
Terminal Type & Cable Compat. Screw‑clamp terminals; supports solid/flexible conductors 0.34–4 mm²
Mounting DIN‑rail or panel mounting
Dimensions (L×W×D) 58 × 90 × 57 mm
Operating Temperature –25 °C to +50 °C
Certifications / Standards IEC 60947‑4‑1/1‑1, NF C 63‑110, VDE 0660, BS 5424; UL, CSA, CCC, EAC; Green Premium compliant
