LP1K1210BD | SCHNEIDER ELECTRIC | TeSys K Contactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 24 V DC Coil

₹ 1,802.15

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LP1K1210BD

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Series / Range TeSys K
Poles 3P – 3 NO (main contacts)
Auxiliary Contact 1 NO (instantaneous)
Rated Operational Current (AC‑3) 12 A @ ≤ 440 V AC (20 A AC‑1)
Motor Power Rating Up to 5.5 kW @ 400 V AC (AC‑3)
Control Coil Voltage 24 V DC
Utilisation Categories AC‑3, AC‑1, AC‑4
Rated Insulation Voltage (Ui) 600 V (UL), 690 V (IEC)
Impulse Withstand Voltage (Uimp) 8 kV
Mechanical Durability ≈ 10 million cycles
Electrical Durability ≈ 1.37 million cycles at nominal load
Operating Rate Up to 3600 cycles/hour
Power Consumption ≈ 3 W (hold‑in & inrush) @ 20 °C
Operating Time 30–40 ms to close, ≈ 10 ms to open
Terminal Type Screw‑clamp (1.3 N·m torque)
Mounting DIN‑rail or panel (screw)
Dimensions (W×D×H) 45 × 57 × 58 mm
Net Weight ≈ 0.225 kg
Operating Temp. −25 °C to +50 °C (−40 °C to +70 °C storage)
Certifications IEC 60947‑4‑1, UL 60947‑4‑1, CSA, CCC, EAC, Marine, Green Premium (RoHS/REACH)
