SPARECRUX is NOT an authorized distributor for CONTRINEX

LTS-3030-104 | CONTRINEX | Compact Diffuse Photoelectric Sensor, PNP, IP67, 10–36V DC

₹ 12,675.53

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LTS-3030-104

Original Equipment Manufacturer

CONTRINEX

Description
Type Diffuse sensor with excess gain
Operating Range Up to 1,200 mm
Housing Dimensions 30 × 30 × 15 mm
Housing Material PBTP (Crastin)
Light Source Infrared LED, 880 nm
Output Type PNP, Light-on with excess gain
Sensitivity Adjustment 12-turn potentiometer
Switching Frequency Up to 1,000 Hz
Supply Voltage 10–36 V DC
Connection M8 4-pin
Ingress Protection IP67
Ambient Temperature Range -25°C to +55°C
Standard Sensing Object 200 × 200 mm (white)
CONTRINEX

LTS-3030-104 | CONTRINEX | Compact Diffuse Photoelectric Sensor, PNP, IP67, 10–36V DC

₹ 12,675.53
Type Diffuse sensor with excess gain
Operating Range Up to 1,200 mm
Housing Dimensions 30 × 30 × 15 mm
Housing Material PBTP (Crastin)
Light Source Infrared LED, 880 nm
Output Type PNP, Light-on with excess gain
Sensitivity Adjustment 12-turn potentiometer
Switching Frequency Up to 1,000 Hz
Supply Voltage 10–36 V DC
Connection M8 4-pin
Ingress Protection IP67
Ambient Temperature Range -25°C to +55°C
Standard Sensing Object 200 × 200 mm (white)
