LUB12 | SCHNEIDER ELECTRIC | Power base, TeSys U, 3P, 12A/690V

₹ 7,238.83

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LUB12

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Specification Details
Product Name LUB12 Power Base
Series TeSys U
Device Type Power Base (Non-Reversing)
Poles 3P
Conventional Free-Air Thermal Current (Ith) 12 A
Rated Operational Current (Ie) 12 A up to 440V / 12 A at 500V / 9 A at 690V
Rated Operational Voltage (Ue) Up to 690 V AC
Rated Insulation Voltage (Ui) 690 V
Utilisation Category AC-41, AC-43, AC-44
Breaking Capacity (Ics) 50 kA at 230V / 50 kA at 440V / 10 kA at 500V
Auxiliary Contacts 1 NO + 1 NC
Power Circuit Terminals Screw Clamp — 1 to 10 mm² (rigid), 1 to 6 mm² (flexible)
Tightening Torque (Power Terminals) 1.9 to 2.5 Nm
Width 45 mm
Height 145 mm
Depth 126 mm
Weight 0.9 kg
Degree of Protection IP20
Operating Temperature -25°C to +70°C
Mechanical Durability 15 million operations
