LV510310 | SCHNEIDER ELECTRIC | EasyPact CVS100B Molded Case Circuit Breaker, 4P 3D, 16A, TM-D Trip Unit

₹ 22,800.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LV510310

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Product Code / Model LV510310 (CVS100B, TM‑D trip unit 16 A)
Poles 4P (3 protected + neutral)
Rated Current (In) 16 A (at 40 °C, adjustable 11.2–16 A)
Trip Unit Type Thermal‑magnetic (TM‑D)
Utilisation Category Category A (distribution)
Breaking Capacity (Icu) 25 kA @ 380/415 V AC
20 kA @ 440 V AC
40 kA @ 220/240 V AC
Rated Service Breaking Capacity (Ics) 25 kA @ 380/415 V AC
15 kA @ 440 V AC
Impulse Withstand Voltage (Uimp) 8 kV (IEC 60947‑2)
Network Frequency 50/60 Hz
Mounting Mode Fixed, backplate mounting
Connection Terminals Screw clamp (front/front connections)
Control Type Toggle switch with contact position indicator
Mechanical Durability ≈ 30,000 cycles
Electrical Durability ≈ 12,000 cycles @ In (415 V AC)
Dimensions (HxWxD) 161 × 140 × 86 mm
Weight ≈ 2.2 kg
Insulation Voltage (Ui) Rated 415 V AC
IP Rating IP40
Pollution / Shock Protection Pollution degree 3, Class II shock protection
Operating Temperature −25 °C … +70 °C
Storage Temperature −50 °C … +85 °C
Standards / Certifications IEC/EN 60947‑2, GOST, RoHS, REACh, Green Premium
