SPARECRUX is NOT an authorized distributor for HAGER

NC106N | HAGER | Single Pole C Curve H3 MCB Breaking Capacity

₹ 235.60

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

NC106N

Original Equipment Manufacturer

HAGER

Description

Specification Details
Brand Hager
Model NC106N
Type Single Pole (SP)
Rated Current 6 A
Tripping Characteristic C-Curve
Breaking Capacity (Icn) 10 kA (IEC 60898-1)
Breaking Capacity (Icu) 15 kA (IEC 60947-2)
Rated Operational Voltage (Ue) 230–400 V AC
Rated Insulation Voltage (Ui) 500 V
Rated Impulse Withstand Voltage (Uimp) 6 kV
Frequency 50–60 Hz
Connection Capacity Rigid: 1–35 mm², Flexible: 1–25 mm²
Electrical Endurance 20,000 cycles
Compliance IEC 60898-1, IEC 60947-2
Dimensions (HxWxD) 2 x 3 x 4 cm
Weight 94 g
Manufacturer Hager Electro Pvt. Ltd., Pune, India
