SPARECRUX is NOT an authorized distributor for HAGER

NCN206N | HAGER | 6A C-Curve 10kA 2 Pole MCB

₹ 834.10

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

NCN206N

Original Equipment Manufacturer

HAGER

Description
Specification Details
Brand Hager
Model NCN106N
Type Single Pole (1P)
Rated Current 6 A
Tripping Characteristic C-Curve (5–10 times rated current)
Breaking Capacity (Icn) 10 kA (per IEC 60898-1)
Breaking Capacity (Icu) 15 kA (per IEC 60947-2)
Rated Operational Voltage (Ue) 230–400 V AC
Rated Insulation Voltage (Ui) 500 V
Rated Impulse Withstand Voltage (Uimp) 6 kV
Frequency 50–60 Hz
Connection Capacity Rigid: 1–35 mm², Flexible: 1–25 mm²
Electrical Endurance 20,000 cycles
Compliance IEC 60898-1, IEC 60947-2
Dimensions (HxWxD) 2 x 3 x 4 cm
Weight 94 g
Manufacturer Hager Electro Pvt. Ltd., Pune, India
