SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA

₹ 1,900.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

OSMC32N2C10

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Device Type Miniature Circuit Breaker, Thermal‑Magnetic
Poles 2P (2‑pole)
Rated Current (In) 10 A
Trip Curve C‑Curve (fast trip for short‑circuit)
Rated Voltage 400–440 VAC
Breaking Capacity (Icu) 6 kA @ 400 VAC
Functions Long‑time + Instantaneous (LI)
Connection Bolt‑on or Clip‑on mounting
Phase Single‑phase (1P+N)
Standards Compliance IEC 60947‑2 / EN 60898
Insulation / Impulse Withstand Ui 500 VAC; Uimp 6 kV
Terminal Capacity Supports up to 16 mm² flexible or 25 mm² solid conductors
Torque (Terminals) ~2.0–2.5 N·m
Durability Mechanical ≥20,000 cycles
Temperature Range −25 °C to +70 °C operation; −40 °C to +85 °C storage
IP / IK Rating IP20; IK04
Weight ≈ 0.24 kg
Certifications IEC/EN 60947‑2, UL 1077 (US), CCC; RoHS / Green Premium compliant
Unit Width 2 modules (≈18 mm)
SCHNEIDER ELECTRIC

OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA

₹ 1,900.00
Device Type Miniature Circuit Breaker, Thermal‑Magnetic
Poles 2P (2‑pole)
Rated Current (In) 10 A
Trip Curve C‑Curve (fast trip for short‑circuit)
Rated Voltage 400–440 VAC
Breaking Capacity (Icu) 6 kA @ 400 VAC
Functions Long‑time + Instantaneous (LI)
Connection Bolt‑on or Clip‑on mounting
Phase Single‑phase (1P+N)
Standards Compliance IEC 60947‑2 / EN 60898
Insulation / Impulse Withstand Ui 500 VAC; Uimp 6 kV
Terminal Capacity Supports up to 16 mm² flexible or 25 mm² solid conductors
Torque (Terminals) ~2.0–2.5 N·m
Durability Mechanical ≥20,000 cycles
Temperature Range −25 °C to +70 °C operation; −40 °C to +85 °C storage
IP / IK Rating IP20; IK04
Weight ≈ 0.24 kg
Certifications IEC/EN 60947‑2, UL 1077 (US), CCC; RoHS / Green Premium compliant
Unit Width 2 modules (≈18 mm)
