SPARECRUX is NOT an authorized distributor for DELTA ELECTRONICS

PFB0624GHE | DELTA ELECTRONICS | DC Fans DC Tubeaxial Fan, 60x38mm, 24VDC, Ball Bearing, Lead Wires, Locked Rotor Sensor

₹ 1,344.14

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

PFB0624GHE

Original Equipment Manufacturer

DELTA ELECTRONICS

Description

Attribute Details
Mfr Delta Electronics
Series PFB
Packaging Bulk
Part Status Active
Voltage - Rated 24VDC
Size / Dimension Square - 60mm L x 60mm H
Width 38.00mm
Air Flow 55.6 CFM (1.56m³/min)
Static Pressure 1.444 in H2O (359.7 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Features Locked Rotor Protection
Noise 57.5 dB(A)
Power (Watts) 11.52 W
RPM 10000 RPM
Termination 2 Wire Leads
Operating Temperature 14 ~ 140°F (-10 ~ 60°C)
Approval Agency CE, CSA, UL, VDE
Weight 0.287 lb (130.18 g)
Current Rating (Amps) 0.480A
Voltage Range 14 ~ 26.4VDC
Material - Frame Plastic
Material - Blade Plastic
Lifetime @ Temp. 50000 Hrs @ 40°C
