R07-200-RNKG | IMI NORGREN | Pressure Regulator

₹ 5,466.89

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

R07-200-RNKG

Original Equipment Manufacturer

IMI NORGREN

Description

Main Function Pressure regulator
Product Series / Family Name Air preparation > Modular components > Regulators (R) > Miniature units
Sub-range Name R07 series
Functions Pneumatic miniature air pressure regulator (R)
Design Relieving diaphragm
Flow 12 dm³/s (25.4 CFM; 720 L/min (LPM); 43.2 m³/h) max.
Pressure +0.3 bar ... +7 bar / +4.35 psi ... +101 psi pressure regulation range
+20 bar / +290 psi max. pressure
Connection Type G1/4" female threaded inlet & outlet ports
Rc1/8" gauge port
Mounting Mode Mounts with wall mounting bracket
Net Height 84 mm
Net Width 42 mm
Net Depth 73 mm
