SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

RB2-BE-102 | SCHNEIDER ELECTRIC | Harmony 22 mm Auxiliary Contact Block, 1 NC, Clip-On, For ZB2 Series Pushbuttons

₹ 2,850.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

RB2-BE-102

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Series / Range Harmony / ZB2 – 22 mm push-button add-on contact block
Contact Configuration 1 NC (Normally Closed)
Rated Current (AC‑15) ≈ 3 A @ 240 V AC
Thermal Current (Ith) 10 A free-air
Rated Insulation Voltage (Ui) 500 V
Insulation Resistance > 2.5 MΩ (at 500 V DC)
Dielectric Strength 2.5 kV for 1 minute
Operating Force ≈ 8 N (NC contact actuation)
Mechanical Life 1 million operations
Operating Temperature −25 °C to +70 °C
Protection Rating IP65/IP66 (panel front use)
Standards IEC 60947‑5‑1, EN 60947‑5‑1
Weight ≈ 0.01 kg (0.04 lb)
SCHNEIDER ELECTRIC

RB2-BE-102 | SCHNEIDER ELECTRIC | Harmony 22 mm Auxiliary Contact Block, 1 NC, Clip-On, For ZB2 Series Pushbuttons

₹ 2,850.00
Series / Range Harmony / ZB2 – 22 mm push-button add-on contact block
Contact Configuration 1 NC (Normally Closed)
Rated Current (AC‑15) ≈ 3 A @ 240 V AC
Thermal Current (Ith) 10 A free-air
Rated Insulation Voltage (Ui) 500 V
Insulation Resistance > 2.5 MΩ (at 500 V DC)
Dielectric Strength 2.5 kV for 1 minute
Operating Force ≈ 8 N (NC contact actuation)
Mechanical Life 1 million operations
Operating Temperature −25 °C to +70 °C
Protection Rating IP65/IP66 (panel front use)
Standards IEC 60947‑5‑1, EN 60947‑5‑1
Weight ≈ 0.01 kg (0.04 lb)
