SHS25LC1SS(GK) | THK | Linear Guide Standard Ball Carriage Profile Rail

₹ 13,204.15

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SHS25LC1SS(GK)

Original Equipment Manufacturer

THK

Description

Rail Size 25 mm
Carriage Length 109 mm
Carriage Width 70 mm
Mounting Height 36 mm
Dynamic Load Rating 36.8 kN
Static Load Rating 64.7 kN
Seal Type SS (end and side seals)
Mounting Holes 4 tapped holes (can be installed from top or bottom)
Ball Arrangement 4-row circular (45° contact angle)
Material Carbon steel
Weight ≈ 0.89 kg
Temperature Range -20°C to +80°C
