THP1-1/8X12FF | FABCO-AIR | Pneumatic Cylinders

₹ 16,266.04

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

THP1-1/8X12FF

Original Equipment Manufacturer

FABCO-AIR

Description

Specification Details
Primary Brand Fabco-Air
Main Function Pneumatic Cylinder
Product Series / Family Name Hi-Power
Sub-Range Name THP Series
Bore Size 1-1/8" (B1-1/8")
Stroke Length 12" (S12")
Functions Double-acting maximum stroke / minimum length tie-rod air cylinder actuator
Design Single Rod
Pressure Range 15 psi min. / 250 psi max.
Shape Rectangular
Connection Type 5/16"-24 UNF-2B Female Threaded Rod-End
2 x 1/8" NPT Threaded Pneumatic Ports
Mounting Mode Front Face Mounting with Fabco Pattern
Material Aluminium Body (Hard Anodized ID / Clear Anodized OD)
Stainless Steel Piston Rod
Aluminium Piston
Buna-N U-Cup Seals
Steel Piston Bolt
Stainless Steel Tie Rods
Plated Steel Nuts
PTFE Piston Bearing
Duralon Rod Bearing
Pre-lubricated with Magnalube-G Grease
Black Anodized Aluminium Rod and Cap End Heads
Black Anodized Aluminium Cap End Plug
Anodized Aluminium Piston Rod Bushing
Operating Temperature -25...+250 °F / -32...+121 °C
