SPARECRUX is NOT an authorized distributor for SCHMERSAL

101115681 | SCHMERSAL | 2 Nc Magnetic Safety Sensor

₹ 14,114.15

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

101115681

الشركة المصنعة للمعدات الأصلية

SCHMERSAL

وصف

Specification Details
Working Principle Magnetic drive
Installation Conditions (Mechanical) Quasi-flush
Housing Material Glass-fibre, reinforced thermoplastic
Material of the Nuts Thermoplastic
Number of Normally Closed (NC) 2
Number of Safety Contacts 2
Actuating Element Magnet
Direction of Motion Head-on to the active surface
Tightening Torque of Nuts (Max.) 3 Nm
Assured Switching Distance "ON" (Sao) 5 mm
Assured Switching Distance "OFF" (Sar) 15 mm
ISO Thread of the Sensor M30
Width Across Flats 36 BK
Length of Sensor 44 mm
Degree of Protection IP67
Ambient Temperature -25 ... +70 °C
Storage and Transport Temperature -25 ... +70 °C
Resistance to Vibrations 10 … 55 Hz, amplitude 1 mm
Resistance to Shock 30 g / 11 ms
Switching Voltage (Max.) 100 VDC
Switching Current (Max.) 0.4 A
Switching Capacity (Max.) 10 W
Switching Element 1 NO contact, 2 NC contacts
Switching Frequency (Max.) 5 Hz
Gross Weight 64 g
