SPARECRUX is NOT an authorized distributor for SCHMERSAL

101193168 | SCHMERSAL | Magnetic Safety Switch

₹ 6,000.00

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

101193168

الشركة المصنعة للمعدات الأصلية

SCHMERSAL

وصف

Attribute Details
Brand Schmersal
Model BNS 36-02ZG-ST-R
Part Number 101193168
Product Type Magnetic safety sensor (non-contact)
Series BNS 36
Contact Configuration 2 NC safety contacts
Operating Principle Magnetic (reed-based)
Actuator Type Separate magnet (BPS series)
Switching Distance (ON) 7 mm
Switching Distance (OFF) 17 mm
Connection Type M8, 4-pin connector
Housing Material Glass-fibre reinforced thermoplastic
Protection Rating IP67
Operating Temperature -25°C to +70°C
Mounting Type Quasi-flush
Safety Standard EN ISO 14119 / EN 60947-5-3
Mechanical Life ~25 million switching cycles (B10d)
Application Safety doors, machine guards, industrial interlocks
