SPARECRUX is NOT an authorized distributor for FESTO

10166 | FESTO | Solenoid Valve JMFH-5-1/2

₹ 6,975.56

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

10166

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Property Value
Valve function 5/2 bistable
Type of actuation Electric
Construction width 52 mm
Standard nominal flow rate (DIN 1343) 4500 l/min
Pneumatic working port G1/2
Operating voltage Via solenoid coil, must be ordered separately
Operating pressure 0.2 MPa ... 0.8 MPa (2 bar ... 8 bar)
Design Poppet seat
Approval c UL us - Recognized (OL)
Degree of protection IP65
Nominal size 14 mm
Grid dimension 69 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position optional
Manual override Detenting
Type of piloting Pilot actuated
Flow direction Non-reversible
Symbol 00995754
lap Underlap
b value 0.3
C value 19.5 l/sbar
Max. switching frequency 25 Hz
Switching time reversal 20 ms
Max. positive test pulse with 0 signal 2200 µs
Max. negative test pulse with 1 signal 3700 µs
Characteristic coil data See solenoid coil, to be ordered separately
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation required if used)
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -20 °C ... 60 °C
Media temperature -10 °C ... 60 °C
Ambient temperature -5 °C ... 40 °C
