1074374 | SICK SENSORS | IMB18-08BDSVU2S Inductive Proximity Sensors

₹ 3,727.80
Get Best Price on WhatsApp

Product Description
Housing Metric
Housing Standard design
Thread size M18 x 1
Diameter Ø 18 mm
Sensing range Sn 8 mm
Safe sensing range Sa 6.48 mm
Installation type Quasi-flush 1)
Switching frequency 1,000 Hz
Connection type Cable, 2-wire, 2 m
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 50 mm
Thread length 45 mm



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1074374

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Standard design

Thread size - M18 × 1

Diameter - Ø 18 mm

Sensing range (Sn) - 8 mm

Safe sensing range (Sa) - 6.48 mm

Installation type - Quasi-flush (1)

Switching frequency - 1,000 Hz

Connection type - Cable, 2-wire, 2 m

Output function - NO

Electrical wiring - DC 2-wire

Supply voltage - 10 V DC … 30 V DC

Ripple - ≤ 10 %

Voltage drop - ≤ 4 V / ≤ 4.5 V

Time delay before availability - ≤ 100 ms

Hysteresis - 3 % … 20 %

Reproducibility - ≤ 2 %

Temperature drift (Sr) - ± 10 %

MTTFD - 1,287 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

ECLASS 5.1.4 - 27270101

ECLASS 6.0 - 27270101

ECLASS 7.0 - 27270101

ECLASS 8.0 - 27270101

ECLASS 9.0 - 27270101

ECLASS 10.0 - 27270101

ECLASS 11.0 - 27270101

ECLASS 12.0 - 27274001
