SPARECRUX is NOT an authorized distributor for FESTO

10773 | FESTO | Pressure Switch PEV-1/4-B

₹ 5,895.78

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

10773

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Category Specification
Standards & Conformity Conforms to EN 60947-5-1
Symbol 00991471
Approvals & Markings CCC, CE (EU Low Voltage Directive), UKCA (UK regulations for electrical equipment)
Explosion Protection Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX) – Certificate info must be observed
Material Compliance RoHS-compliant
Measured Variable Relative pressure
Measurement Method Pneumatic/electric pressure transducer
Operating Pressure 0.1 MPa … 1.2 MPa (1 bar … 12 bar)
Operating Medium Compressed air to ISO 8573-1:2010 [7:-:-], Water
Note on Medium Lubricated operation possible (if lubricated, must always remain lubricated)
Media Temperature -20 °C … 80 °C
Ambient Temperature -20 °C … 80 °C
Switching Element Function Changeover switch
Max. Switching Frequency 3 Hz
Max. Switching Output Voltage (AC) 250 V
Max. Switching Output Voltage (DC) 125 V
Max. Output Current 5000 mA
Min. Load Current 1 mA at 24 V, 10 mA at 10 V, 100 mA at 5 V
Utilisation Category - Inductive Load AC-14, DC-13
Utilisation Category - Resistive Load AC-12, DC-12
Electrical Connection Type A, Plugs to DIN 43650, Square design
Mounting Type With through-hole
Mounting Position Optional
Pneumatic Connection G1/4
Product Weight 194 g
Housing Material Die-cast aluminium
Switch Contact Material Silver
Threshold Value Setting Range 1 bar … 12 bar
Degree of Protection IP65
Corrosion Resistance Class CRC2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
