SPARECRUX is NOT an authorized distributor for FESTO

123062 | FESTO | Solenoid Coil MSN1W-230AC-OD

₹ 518.49

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

123062

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Value
Mounting position Optional
Min. pick-up time 10 ms
Duty cycle 100%
Power factor (cos φ) 0.7
Coil Data (230 V AC, 50 Hz) Pick-up: 7.5 VAHolding: 5.0 VA
Coil Data (230 V AC, 60 Hz) Pick-up: 5.0 VAHolding: 3.7 VA
Permissible voltage fluctuation ±10%
Protection class IP65
Ambient temperature -10 °C ... +50 °C
Media temperature -10 °C ... +50 °C
Weight 80 g
Electrical connection 3-pin, Type A (per DIN EN 175301-803)
Mounting Via retaining clamp / With accessories
Certification DNV-TAA000032X, CE (EU LVD), UKCA
PWIS (LABS) conformity VDMA24364-C1-L
Material – Housing Polyamide (PA)
Material – Electrical contact Steel
Material – Winding Copper
FESTO

123062 | FESTO | Solenoid Coil MSN1W-230AC-OD

₹ 518.49
Parameter Value
Mounting position Optional
Min. pick-up time 10 ms
Duty cycle 100%
Power factor (cos φ) 0.7
Coil Data (230 V AC, 50 Hz) Pick-up: 7.5 VAHolding: 5.0 VA
Coil Data (230 V AC, 60 Hz) Pick-up: 5.0 VAHolding: 3.7 VA
Permissible voltage fluctuation ±10%
Protection class IP65
Ambient temperature -10 °C ... +50 °C
Media temperature -10 °C ... +50 °C
Weight 80 g
Electrical connection 3-pin, Type A (per DIN EN 175301-803)
Mounting Via retaining clamp / With accessories
Certification DNV-TAA000032X, CE (EU LVD), UKCA
PWIS (LABS) conformity VDMA24364-C1-L
Material – Housing Polyamide (PA)
Material – Electrical contact Steel
Material – Winding Copper
