SPARECRUX is NOT an authorized distributor for FESTO

151169 | FESTO | One-way Flow Control valve GRLA-1/8-RS-B

₹ 1,954.02

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

151169

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Specification Details
Valve function Exhaust air one-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Knurled screw
Type of mounting Screw-in
Standard nominal flow rate in flow control direction 340 l/min
Standard nominal flow rate in blocked direction 260 l/min ... 420 l/min
Ambient temperature -10 °C ... 60 °C
Maritime classification See certificate
Explosion protection The information in the certificate must be observed!
Zone 1 (ATEX)
Zone 2 (ATEX)
Zone 21 (ATEX)
Zone 22 (ATEX)
Mounting position optional
Symbol 00991452
Operating pressure complete temperature range 0.3 bar ... 10 bar
Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) 615 l/min
Standard flow rate in non-return direction 0.6->0 MPa (6->0 bar, 87->0 psi) 470 l/min ... 760 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Media temperature -10 °C ... 60 °C
Max. tightening torque 6 Nm
Product weight 30 g
Material screwed plug Wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR
Material adjusting screw Brass
