SPARECRUX is NOT an authorized distributor for FESTO

151687 | FESTO | Plug Socket MSSD-EB

₹ 120.37

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

151687

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Specification Details
Type of mounting On solenoid valve via M2.5 central screw
Cable outlet Angled
Note on cable outlet 90° rotatable
Mounting position optional
Product weight 11 g
Electrical connection 3-pin
Socket Angled socket
Type C To DIN EN 175301-803
To DIN EN 61984
Square design MSEB
Square design MSN2
Electrical connection 1, design Angular
Electrical connection 1, connection type Socket
Electrical connection 1, cable outlet Angled
Electrical connection 1, number of connections/cores 3
Electrical connection 1, connection pattern 00995650
Electrical connection 2 Screw terminal
Operational voltage range DC 0 V ... 300 V
Operational voltage range AC 0 V ... 250 V
Current rating at 40° C 6 A
Permissible current load 6 A
Immunity to surge 4 kV
Protective conductor connection Available
Cable fitting Pg7
Cable diameter 6 mm ... 8 mm
Permissible cable diameter 7.5 mm
Nominal cross section conductor ≤0.75 mm²
Connection cross section 0.75 mm²
Degree of protection IP65
To IEC 60529
Note on degree of protection In assembled state
Ambient temperature -45 °C ... 90 °C
CE mark (see declaration of conformity) To EU Low Voltage Directive
In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity) To UK RoHS instructions
To UK regulations for electrical equipment
LABS (PWIS) conformity VDMA24364-B2-L
Pollution degree 3
Material housing Polymer
Housing colour Black
Material seals NBR
FESTO

151687 | FESTO | Plug Socket MSSD-EB

₹ 120.37
Specification Details
Type of mounting On solenoid valve via M2.5 central screw
Cable outlet Angled
Note on cable outlet 90° rotatable
Mounting position optional
Product weight 11 g
Electrical connection 3-pin
Socket Angled socket
Type C To DIN EN 175301-803
To DIN EN 61984
Square design MSEB
Square design MSN2
Electrical connection 1, design Angular
Electrical connection 1, connection type Socket
Electrical connection 1, cable outlet Angled
Electrical connection 1, number of connections/cores 3
Electrical connection 1, connection pattern 00995650
Electrical connection 2 Screw terminal
Operational voltage range DC 0 V ... 300 V
Operational voltage range AC 0 V ... 250 V
Current rating at 40° C 6 A
Permissible current load 6 A
Immunity to surge 4 kV
Protective conductor connection Available
Cable fitting Pg7
Cable diameter 6 mm ... 8 mm
Permissible cable diameter 7.5 mm
Nominal cross section conductor ≤0.75 mm²
Connection cross section 0.75 mm²
Degree of protection IP65
To IEC 60529
Note on degree of protection In assembled state
Ambient temperature -45 °C ... 90 °C
CE mark (see declaration of conformity) To EU Low Voltage Directive
In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity) To UK RoHS instructions
To UK regulations for electrical equipment
LABS (PWIS) conformity VDMA24364-B2-L
Pollution degree 3
Material housing Polymer
Housing colour Black
Material seals NBR
