SPARECRUX is NOT an authorized distributor for FESTO

153096 | FESTO | Push-in L-fitting QSLV-1/2-16

₹ 773.97

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

153096

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Details
Size Standard
Nominal size 13 mm
Type of seal on screwed plug Coating
Mounting position optional
Design L-shape
Size of pack 1
Design Push-pull principle
Operating pressure complete temperature range -0.095 MPa ... 0.6 MPa
-0.95 bar ... 6 bar
-13.775 psi ... 87 psi
Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa
-0.95 bar ... 14 bar
-13.775 psi ... 203 psi
Note on operating pressure Water: max. 0.6 MPa at max. 50°C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Water (liquid, ice-free)
Note on operating and pilot medium Lubricated operation possible
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Ambient temperature -10 °C ... 80 °C
Nominal torque 26 Nm
Tolerance for nominal tightening torque ± 20%
Product weight 105 g
Type of mounting Hollow bolt with external hex
Pneumatic connection, port 1 Male thread R1/2
